Specifications:
Rated current: 0.3 to 0.5A AC, DC
Rated voltage: 30V DC
Temperature range: -40 deg C to +105 deg C
Contact resistance: 20m Omega Max.
Insulation resistance: 100M Omega Min.
Withstand pressure: 200V AC/minute
Housing: PA66 94V-0 Natural color/black
Terminal material: phosphor copper gold plated/tin
Pin body material: LCP-94V-0 Natural color/black
PIN Pin material: phosphor copper gold plated/tin
Pin holder ground disc material: phosphor tin plated
| Brand | Model A | Model B | Model C | Model D | CSG Model | Description |
| JST | 02SUR-32S | 02SUR-32S(HF) | 02SUR-32S(HF) | 2SUR-32S | A0800HI002AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,2 Circuits,Gold(Au) Plating,Natural(White) |
| JST | 03SUR-32S | 03SUR-32S(HF) | 03SUR-32S(HF) | 3SUR-32S | A0800HI003AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,3 Circuits,Gold(Au) Plating,Natural(White) |
| JST | 04SUR-32S | 04SUR-32S(HF) | 04SUR-32S(HF) | 4SUR-32S | A0800HI004AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,4 Circuits,Gold(Au) Plating,Natural(White) |
| JST | 05SUR-32S | 05SUR-32S(HF) | 05SUR-32S(HF) | 5SUR-32S | A0800HI005AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,5 Circuits,Gold(Au) Plating,Natural(White) |
| JST | 06SUR-32S | 06SUR-32S(HF) | 06SUR-32S(HF) | 6SUR-32S | A0800HI006AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,6 Circuits,Gold(Au) Plating,Natural(White) |
| JST | 07SUR-32S | 07SUR-32S(HF) | 07SUR-32S(HF) | 7SUR-32S | A0800HI007AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,7 Circuits,Gold(Au) Plating,Natural(White) |
| JST | 08SUR-32S | 08SUR-32S(HF) | 08SUR-32S(HF) | 8SUR-32S | A0800HI008AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,8 Circuits,Gold(Au) Plating,Natural(White) |
| JST | 09SUR-32S | 09SUR-32S(HF) | 09SUR-32S(HF) | 9SUR-32S | A0800HI009AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,9 Circuits,Gold(Au) Plating,Natural(White) |
| JST | 10SUR-32S | 10SUR-32S(HF) | 10SUR-32S(HF) | A0800HI010AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,10 Circuits,Gold(Au) Plating,Natural(White) | |
| JST | 11SUR-32S | 11SUR-32S(HF) | 11SUR-32S(HF) | A0800HI011AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,11 Circuits,Gold(Au) Plating,Natural(White) | |
| JST | 12SUR-32S | 12SUR-32S(HF) | 12SUR-32S(HF) | A0800HI012AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,12 Circuits,Gold(Au) Plating,Natural(White) | |
| JST | 14SUR-32S | 14SUR-32S(HF) | 14SUR-32S(HF) | A0800HI014AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,14 Circuits,Gold(Au) Plating,Natural(White) | |
| JST | 15SUR-32S | 15SUR-32S(HF) | 15SUR-32S(HF) | A0800HI015AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,15 Circuits,Gold(Au) Plating,Natural(White) | |
| JST | 16SUR-32S | 16SUR-32S(HF) | 16SUR-32S(HF) | A0800HI016AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,16 Circuits,Gold(Au) Plating,Natural(White) | |
| JST | 18SUR-32S | 18SUR-32S(HF) | 18SUR-32S(HF) | A0800HI018AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,18 Circuits,Gold(Au) Plating,Natural(White) | |
| JST | 20SUR-32S | 20SUR-32S(HF) | 20SUR-32S(HF) | A0800HI020AAP6GFA9182 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,20 Circuits,Gold(Au) Plating,Natural(White) | |
| JST | 22SUR-32S | 22SUR-32S(HF) | 22SUR-32S(HF) | A0800HI022AAP4GFA9001 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,22 Circuits,Gold(Au) Plating,Natural(White) | |
| JST | 24SUR-32S | 24SUR-32S(HF) | 24SUR-32S(HF) | A0800HI024AAP4GFA9001 | 0.80mm(.0315in)Pitch,Receptacle IDC Connectors,Friction Lock,Socket,24 Circuits,Gold(Au) Plating,Natural(White) | |
| JST | BM02B-SURS-TF(LF)(SN) | BM02B-SURS-TFT(LF)(SN) | BM02B-SURS-TF(LF)(SN) | BM02B-SURS-TFT(LF)(SN) | A0800VS002AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,2 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM03B-SURS-TF(LF)(SN) | BM03B-SURS-TFT(LF)(SN) | BM03B-SURS-TF(LF)(SN) | BM03B-SURS-TFT(LF)(SN) | A0800VS003AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,3 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM04B-SURS-TF(LF)(SN) | BM04B-SURS-TFT(LF)(SN) | BM04B-SURS-TF(LF)(SN) | BM04B-SURS-TFT(LF)(SN) | A0800VS004AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,4 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM05B-SURS-TF(LF)(SN) | BM05B-SURS-TFT(LF)(SN) | BM05B-SURS-TF(LF)(SN) | BM05B-SURS-TFT(LF)(SN) | A0800VS005AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,5 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM06B-SURS-TF(LF)(SN) | BM06B-SURS-TFT(LF)(SN) | BM06B-SURS-TF(LF)(SN) | BM06B-SURS-TFT(LF)(SN) | A0800VS006AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,6 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM07B-SURS-TF(LF)(SN) | BM07B-SURS-TFT(LF)(SN) | BM07B-SURS-TF(LF)(SN) | BM07B-SURS-TFT(LF)(SN) | A0800VS007AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,7 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM08B-SURS-TF(LF)(SN) | BM08B-SURS-TFT(LF)(SN) | BM08B-SURS-TF(LF)(SN) | BM08B-SURS-TFT(LF)(SN) | A0800VS008AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,8 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM09B-SURS-TF(LF)(SN) | BM09B-SURS-TFT(LF)(SN) | BM09B-SURS-TF(LF)(SN) | BM09B-SURS-TFT(LF)(SN) | A0800VS009AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,9 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM10B-SURS-TF(LF)(SN) | BM10B-SURS-TFT(LF)(SN) | BM10B-SURS-TF(LF)(SN) | BM10B-SURS-TFT(LF)(SN) | A0800VS010AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,10 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM11B-SURS-TF(LF)(SN) | BM11B-SURS-TFT(LF)(SN) | BM11B-SURS-TF(LF)(SN) | BM11B-SURS-TFT(LF)(SN) | A0800VS011AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,11 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM12B-SURS-TF(LF)(SN) | BM12B-SURS-TFT(LF)(SN) | BM12B-SURS-TF(LF)(SN) | BM12B-SURS-TFT(LF)(SN) | A0800VS012AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,12 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM13B-SURS-TF(LF)(SN) | BM13B-SURS-TFT(LF)(SN) | BM13B-SURS-TF(LF)(SN) | BM13B-SURS-TFT(LF)(SN) | A0800VS013AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,13 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM14B-SURS-TF(LF)(SN) | BM14B-SURS-TFT(LF)(SN) | BM14B-SURS-TF(LF)(SN) | BM14B-SURS-TFT(LF)(SN) | A0800VS014AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,14 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM15B-SURS-TF(LF)(SN) | BM15B-SURS-TFT(LF)(SN) | BM15B-SURS-TF(LF)(SN) | BM15B-SURS-TFT(LF)(SN) | A0800VS015AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,15 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM16B-SURS-TF(LF)(SN) | BM16B-SURS-TFT(LF)(SN) | BM16B-SURS-TF(LF)(SN) | BM16B-SURS-TFT(LF)(SN) | A0800VS016AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,16 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM18B-SURS-TF(LF)(SN) | BM18B-SURS-TFT(LF)(SN) | BM18B-SURS-TF(LF)(SN) | BM18B-SURS-TFT(LF)(SN) | A0800VS018AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,18 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM20B-SURS-TF(LF)(SN) | BM20B-SURS-TFT(LF)(SN) | BM20B-SURS-TF(LF)(SN) | BM20B-SURS-TFT(LF)(SN) | A0800VS020AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,20 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM22B-SURS-TF(LF)(SN) | BM22B-SURS-TFT(LF)(SN) | BM22B-SURS-TF(LF)(SN) | BM22B-SURS-TFT(LF)(SN) | A0800VS022AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,22 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM24B-SURS-TF(LF)(SN) | BM24B-SURS-TFT(LF)(SN) | BM24B-SURS-TF(LF)(SN) | BM24B-SURS-TFT(LF)(SN) | A0800VS024AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,24 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM28B-SURS-TF(LF)(SN) | BM28B-SURS-TFT(LF)(SN) | BM28B-SURS-TF(LF)(SN) | BM28B-SURS-TFT(LF)(SN) | A0800VS028AZLPTPB8001 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,28 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | BM02B-SURS-GAN-TF | BM02B-SURS-GAN-TFT | BM2B-SURS-GAN-TF | BM2B-SURS-GAN-TFT | A0800VS002AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,2 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | BM03B-SURS-GAN-TF | BM03B-SURS-GAN-TFT | BM3B-SURS-GAN-TF | BM3B-SURS-GAN-TFT | A0800VS003AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,3 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | BM04B-SURS-GAN-TF | BM04B-SURS-GAN-TFT | BM4B-SURS-GAN-TF | BM4B-SURS-GAN-TFT | A0800VS004AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,4 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | BM05B-SURS-GAN-TF | BM05B-SURS-GAN-TFT | BM5B-SURS-GAN-TF | BM5B-SURS-GAN-TFT | A0800VS005AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,5 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | BM06B-SURS-GAN-TF | BM06B-SURS-GAN-TFT | BM6B-SURS-GAN-TF | BM6B-SURS-GAN-TFT | A0800VS006AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,6 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | BM07B-SURS-GAN-TF | BM07B-SURS-GAN-TFT | BM7B-SURS-GAN-TF | BM7B-SURS-GAN-TFT | A0800VS007AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,7 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | BM08B-SURS-GAN-TF | BM08B-SURS-GAN-TFT | BM8B-SURS-GAN-TF | BM8B-SURS-GAN-TFT | A0800VS008AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,8 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | BM09B-SURS-GAN-TF | BM09B-SURS-GAN-TFT | BM9B-SURS-GAN-TF | BM9B-SURS-GAN-TFT | A0800VS009AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,9 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | BM10B-SURS-GAN-TF | BM10B-SURS-GAN-TFT | A0800VS010AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,10 Circuits,Gold(Au)Plating,UL 94V-0 Gray | ||
| JST | BM11B-SURS-GAN-TF | BM11B-SURS-GAN-TFT | A0800VS011AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,11 Circuits,Gold(Au)Plating,UL 94V-0 Gray | ||
| JST | BM12B-SURS-GAN-TF | BM12B-SURS-GAN-TFT | A0800VS012AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,12 Circuits,Gold(Au)Plating,UL 94V-0 Gray | ||
| JST | BM13B-SURS-GAN-TF | BM13B-SURS-GAN-TFT | A0800VS013AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,13 Circuits,Gold(Au)Plating,UL 94V-0 Gray | ||
| JST | BM14B-SURS-GAN-TF | BM14B-SURS-GAN-TFT | A0800VS014AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,14 Circuits,Gold(Au)Plating,UL 94V-0 Gray | ||
| JST | BM15B-SURS-GAN-TF | BM15B-SURS-GAN-TFT | A0800VS015AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,15 Circuits,Gold(Au)Plating,UL 94V-0 Gray | ||
| JST | BM16B-SURS-GAN-TF | BM16B-SURS-GAN-TFT | A0800VS016AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,16 Circuits,Gold(Au)Plating,UL 94V-0 Gray | ||
| JST | BM18B-SURS-GAN-TF | BM18B-SURS-GAN-TFT | A0800VS018AVLPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Vertical,18 Circuits,Gold(Au)Plating,UL 94V-0 Gray | ||
| JST | SM02B-SURS-TF(LF)(SN) | SM02B-SURS-ETF(LF)(SN) | SM02B-SURS-TF(LF)(SN) | A0800RS002AALPTPB8182 | A0800RS002AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,2 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM03B-SURS-TF(LF)(SN) | SM03B-SURS-ETF(LF)(SN) | SM03B-SURS-TF(LF)(SN) | A0800RS003AALPTPB8182 | A0800RS003AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,3 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM04B-SURS-TF(LF)(SN) | SM04B-SURS-ETF(LF)(SN) | SM04B-SURS-TF(LF)(SN) | A0800RS004AALPTPB8182 | A0800RS004AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,4 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM05B-SURS-TF(LF)(SN) | SM05B-SURS-ETF(LF)(SN) | SM05B-SURS-TF(LF)(SN) | A0800RS005AALPTPB8182 | A0800RS005AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,5 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM06B-SURS-TF(LF)(SN) | SM06B-SURS-ETF(LF)(SN) | SM06B-SURS-TF(LF)(SN) | A0800RS006AALPTPB8182 | A0800RS006AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,6 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM07B-SURS-TF(LF)(SN) | SM07B-SURS-ETF(LF)(SN) | SM07B-SURS-TF(LF)(SN) | A0800RS007AALPTPB8182 | A0800RS007AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,7 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM08B-SURS-TF(LF)(SN) | SM08B-SURS-ETF(LF)(SN) | SM08B-SURS-TF(LF)(SN) | A0800RS008AALPTPB8182 | A0800RS008AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,8 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM09B-SURS-TF(LF)(SN) | SM09B-SURS-ETF(LF)(SN) | SM09B-SURS-TF(LF)(SN) | A0800RS009AALPTPB8182 | A0800RS009AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,9 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM10B-SURS-TF(LF)(SN) | SM10B-SURS-ETF(LF)(SN) | SM10B-SURS-TF(LF)(SN) | A0800RS010AALPTPB8182 | A0800RS010AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,10 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM11B-SURS-TF(LF)(SN) | SM11B-SURS-ETF(LF)(SN) | SM11B-SURS-TF(LF)(SN) | A0800RS011AALPTPB8182 | A0800RS011AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,11 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM12B-SURS-TF(LF)(SN) | SM12B-SURS-ETF(LF)(SN) | SM12B-SURS-TF(LF)(SN) | A0800RS012AALPTPB8182 | A0800RS012AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,12 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM13B-SURS-TF(LF)(SN) | SM13B-SURS-ETF(LF)(SN) | SM13B-SURS-TF(LF)(SN) | A0800RS013AALPTPB8182 | A0800RS013AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,13 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM14B-SURS-TF(LF)(SN) | SM14B-SURS-ETF(LF)(SN) | SM14B-SURS-TF(LF)(SN) | A0800RS014AALPTPB8182 | A0800RS014AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,14 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM15B-SURS-TF(LF)(SN) | SM15B-SURS-ETF(LF)(SN) | SM15B-SURS-TF(LF)(SN) | A0800RS015AALPTPB8182 | A0800RS015AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,15 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM16B-SURS-TF(LF)(SN) | SM16B-SURS-ETF(LF)(SN) | SM16B-SURS-TF(LF)(SN) | A0800RS016AALPTPB8182 | A0800RS016AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,16 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM18B-SURS-TF(LF)(SN) | SM18B-SURS-ETF(LF)(SN) | SM18B-SURS-TF(LF)(SN) | A0800RS018AALPTPB8182 | A0800RS018AALPTPB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,18 Circuits,Tin(Sn)Plating,UL 94V-0 Gray |
| JST | SM02B-SURS-GAN-G-TF | SM02B-SURS-EGAN-G-TF | SM2B-SURS-GAN-G-TF | A0800RS002AALPGFB8182 | A0800RS002AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,2 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | SM03B-SURS-GAN-G-TF | SM03B-SURS-EGAN-G-TF | SM3B-SURS-GAN-G-TF | A0800RS003AALPGFB8182 | A0800RS003AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,3 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | SM04B-SURS-GAN-G-TF | SM04B-SURS-EGAN-G-TF | SM4B-SURS-GAN-G-TF | A0800RS004AALPGFB8182 | A0800RS004AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,4 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | SM05B-SURS-GAN-G-TF | SM05B-SURS-EGAN-G-TF | SM5B-SURS-GAN-G-TF | A0800RS005AALPGFB8182 | A0800RS005AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,5 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | SM06B-SURS-GAN-G-TF | SM06B-SURS-EGAN-G-TF | SM6B-SURS-GAN-G-TF | A0800RS006AALPGFB8182 | A0800RS006AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,6 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | SM07B-SURS-GAN-G-TF | SM07B-SURS-EGAN-G-TF | SM7B-SURS-GAN-G-TF | A0800RS007AALPGFB8182 | A0800RS007AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,7 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | SM08B-SURS-GAN-G-TF | SM08B-SURS-EGAN-G-TF | SM8B-SURS-GAN-G-TF | A0800RS008AALPGFB8182 | A0800RS008AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,8 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | SM09B-SURS-GAN-G-TF | SM09B-SURS-EGAN-G-TF | SM9B-SURS-GAN-G-TF | A0800RS009AALPGFB8182 | A0800RS009AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,9 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
| JST | SM10B-SURS-GAN-G-TF | SM10B-SURS-EGAN-G-TF | A0800RS010AALPGFB8182 | A0800RS010AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,10 Circuits,Gold(Au)Plating,UL 94V-0 Gray | |
| JST | SM11B-SURS-GAN-G-TF | SM11B-SURS-EGAN-G-TF | A0800RS011AALPGFB8182 | A0800RS011AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,11 Circuits,Gold(Au)Plating,UL 94V-0 Gray | |
| JST | SM12B-SURS-GAN-G-TF | SM12B-SURS-EGAN-G-TF | A0800RS012AALPGFB8182 | A0800RS012AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,12 Circuits,Gold(Au)Plating,UL 94V-0 Gray | |
| JST | SM13B-SURS-GAN-G-TF | SM13B-SURS-EGAN-G-TF | A0800RS013AALPGFB8182 | A0800RS013AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,13 Circuits,Gold(Au)Plating,UL 94V-0 Gray | |
| JST | SM14B-SURS-GAN-G-TF | SM14B-SURS-EGAN-G-TF | A0800RS014AALPGFB8182 | A0800RS014AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,14 Circuits,Gold(Au)Plating,UL 94V-0 Gray | |
| JST | SM15B-SURS-GAN-G-TF | SM15B-SURS-EGAN-G-TF | A0800RS015AALPGFB8182 | A0800RS015AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,15 Circuits,Gold(Au)Plating,UL 94V-0 Gray | |
| JST | SM16B-SURS-GAN-G-TF | SM16B-SURS-EGAN-G-TF | A0800RS016AALPGFB8182 | A0800RS016AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,16 Circuits,Gold(Au)Plating,UL 94V-0 Gray | |
| JST | SM18B-SURS-GAN-G-TF | SM18B-SURS-EGAN-G-TF | A0800RS018AALPGFB8182 | A0800RS018AALPGFB8109 | 0.80mm(.0315in)Pitch,Header,SMD,Right-Angle,18 Circuits,Gold(Au)Plating,UL 94V-0 Gray |
